Brand: LED SPEKTAR
Model: PH6.67
Type: Outdoor LED Display
Technical specification:
Characteristics of LEDs:
LED brand: Epistar
Luminous intensity:
800-1000mcd (Red)
1600-1800mcd (Green)
350mcd (Blue)
Characteristics of the module:
Pixel Pitch: 6.67mm
Pixel configuration: 1R1G1B
Resolution of the module: 48 x 48
Number of pixels per module: 2300
Size of module: 320Mm x 320mm
Weight of the unit: 2.2 kg
Characteristics of the study:
Size of the Cabinet: 960 x 1600mm (black)
Resolution of the Cabinet: 144 x 240
Number of pixels cabinet: 34.560
Pixel density: 22.476 pixels / sqm
Average power consumption: 220W / sqm
Maximum power consumption: 680W / sqm
Material: metal and steel
Cabinet weight: 80 kg
Parameters screen:
Brightness: ≥ 6500cd / sqm
Driving method: 1/8 scan same current
viewing angle: 120/60
Optimal viewing distance: 6-80 meters
Refresh rate: ≥ 1800Hz
Frame rate: 50-60Hz
Voltage: AC220V / 50Hz AC or 110 / 60Hz
Frequency of defects: ≥0.00001
Type chip: MBI5020B
life:> 100,000 hours
IP: IP 67 front, IP65 back
Operating temperature: -40 ° ~ + 60 °
Operating humidity: 10% ~ 95%
Control system: NOVA
Power supply: Meanwell
Applicable places: Indoor and outdoor advertising outlets that have limited space.
