Brand: LED SPEKTAR
Model: N6
Type: Indoor SMD
Technical specification:
Pixel Pitch: 6mm
Module size: 192*192mm
Pixel density: 27 777dots/m²
LED Configuration: 1R1G1B
LED encapsulation: SMD2121
LED: NationStar
Resolution of the module: 32*32dots
Module Max. Power: 21.6W
Optimal viewing distance: ≥6m
Optimum viewing angle: H140° / V130°
Max. power consumption: 773W/m²
Cabinet size: 576*576mm
Resolution of the Cabinet: 96*96dots
Weight screen: 28kg/m²
Driving method: 1/8 scan Constant Current
Brightness: ≥800cd/m²
Frame frequency: ≥60Hz/s
Refresh rate (Hz): ≥720Hz
Operating environment: Temperature: -20°C~ + 50°C, Humidity: 10% ~ 90%RH
IP Protection: IP30
Operating voltage: AC110V/220V ±10%
Percentage of defective pixels: < 0.0001
Lifespan of LEDs: ≥10.000 hours
Application: Advertisment displays for indoor usage.
