Brand: ChovA
Model: ViscoLAM 65
Type: Soundproofing membrane
Note: The price is for m² !!!
Description:
Elastic high density viscous wadding, specially designed to improve sound insulation in various soundproofing systems.
Excellent barrier to noise transmission due to material properties such as high density (1600 kg / m3), strong isolation factor and required elasticity.
Technical Characteristics:
Thickness (mm): 4mm
Density (kg / m3): 1600 kg / m³
Average weight (kg / m²): 6.5kg
Sound insulation (Rw, dB): 67 dB for impact noise
Theoretical calculations. Test LABEIN B130 by CT-109 I
Dimensions (m): 5.5x1m
M² / pallet: 137m²
Installation:
Cut a portion of ViscoLAM 65 according to the size of the partition designed for soundproofing using a cutting tool.
Fix ViscoLAM 65 on the gypsum board in any of the following ways:
Through metal screws with fixing washer
Using brackets (8, 10 or 12 mm)
By contact glue.
Placing must be done against gypsum board joints.
Repeat the following steps the required number of times according to the soundproofing system you selected.
Warranty: Life of the building
Application:
Reinforcement of acoustic systems with wooden constructions or plasterboard.
Cases with limited space for sound insulation
Acoustic insulation and vibration reduction in metal sheet structures.
Design of various acoustic solutions and alternatives such as doors, screens, soundproof walls.
