Brand: ОЕМ
Model: 10W
Type: RGB Laser
Description:
1. Full pure diode RGB laser with more stable performance and longer working life.The machine can work in -20°C- 50°C.
2. Two floors designs, more compacted and much lighter.
1) Top floor: Optical and electric components. Dust proof designs, no maintenance costs. Electric components on the top floor, easy
to install and replace. The heat is transmitted to the heat sink.
2) Bottom floor: Heat sink floor. The high speed fans will blow away the heat and keep the machine in good working temperature.
3. Made of analog laser modulation. Users can dimmer the laser brightness linearly to makes the laser light more colorful.
4. Use LCD display technology, SD card functions. All the pattern sizes, sensitivity, color setting, scanner speed and mirror image, etc
are set by button. Easy to operate and understand. Lower the hardware failure rates.
◆Play Mode: ILDA PC Control，DMX512, Sound Active, AUTO, Master/Slave.
◆PC control: Compatible ILDA laser show software with ILDA interface. Use electronic switches to convert full ILDA signal.
◆Safety configure: Single Beam Protection System(can switch ON or OFF; single beam protection system is very important system
for high power laser lights), Power key switch, laser ON-OFF switch, laser remote interlock, flying rings bolt.
◆Safety intelligent: Automatically identify ILDA or built-in program mode. Master/slave mode, DMX512 and PC control mode, will
shut off laser automatically without trigger signal.the scanner failure protection will shut off the laser signal and the
shutter will block the laser output automatically, so as to avoid the single beam coming out.
Technical parameters:
Power Supply: 100~250V, 50/60Hz
Power consumption 100W
Red Laser:
Power:3W
Wavelength: 638nm
Green Laser:
Power:3W
Wavelength: 520nm
Blue Laser:
Power:>4W
Wavelength: 450nm
Scanner:
1)40KPPS, ±30°
Machine Size : 255*195*165(H)mm
Weight: 12kg
Application: Disco, Clubs, KTV, Pub, Bar, family party, etc.
