Brand: HED AUDIO
Model: PAM 360
Type: Amplifier
Description: Commercial grade, single-channel amplifier, which successfully delivered to 360W reliable clean sound, suitable for even the most demanding audience or use voice alarms. Firmly built to deliver reliable service for years, equipped with massive transformers, cooling fans, safeguards against overheating, short circuit, RFI and soft start.
100V, 70V and 4 Ohm speakers isolated
Balanced XLR input with parallel XLR output connector
400Hz high pass filter
Ground Selector Switch: Frame / Float
Adjustable power output signal: -12dB to 0dB
Specifications:
Rated output power: 360W / 100V
Frequency response: 60Hz - 20KHz, + / - 3db
THD: <1,0% at 1 kHz (1/2 rated power)
Signal / noise ratio> 90 dB
Power consumption: 760W
Power: 220-240V AC, 50/60 Hz; 24V DC
Dimensions (HxWxD): 89 x 483 x 377 mm, 19 "Rack Mount, 2HU
Net weight: 20.8 kg
