Brand: LED SPEKTAR
Model: PH12 DIP 2R1G1B LED DISPLAY
Type: Fixed installation Outdoor LED DIP RGB display
Description: The external LED displays offered by LED SPEKTAR are with high brightness and frequency, which ensures crystal clear picture of the picture. The use of first-class LED chips brands EPISTAR and SILAN which ensures long life of LED display and clarity even in direct sunlight. The return on investment is fast due to their widespread use.
Technical characteristics: PH 12 DIP RGB external display
Pixel Pitch: 12 mm
Pixel density: 6944pix / m2
Type of LED: 2R1G1B
Wavelength of the LEDs: R: 620-630 / G: 520-530 / B: 465-475
Luminous intensity of the LEDs: R: 415-490 / G: 1880-2225 / B: 415-490
Viewing Angle: H 110 °, V70 °
Brightness: ≥6000cd / m2
Control method: Static constant current
Colour Depth: 16,384 grade / each
Refresh rate (Hz): ≥300
Frame Rate (Hz): ≥60
Adjusting the brightness manually, automatically, SPC
Module Size (mm): 192x192mm
Module Resolution (pixel): 16x16
Size of cabinet (mm): 960x960x225mm
Display Resolution of the Cabinet: 80x80
Most good viewing distance: 12-100m (depending on screen size)
Material of cabinet: steel (aluminum optional)
Cabinet Weight (kg): 46 kg.
Voltage (V): AC 110 - 220V / 50Hz
Max. Power consumption: 650W / m2
Average power consumption: 290W / m2
IP grade: Front panel IP65 / IP43 Rear panel
Temperature / humidity operation: -20º ~ 50º, 10 ~ 90% RH
Storage temperature / humidity: -40º ~ 60º, 10 ~ 90% RH
Life (Normal Temp): ≥100000 H
Control: Linsn
Connecting cables: 120 m (CAT5E); 500m-10km (optichnen cable)
Supported devices: DVI, DVD, HDVD, video camera
Compatible standards: CCC, CE
Applicable places: For fixed installations, mobile media, outdoor advertising, stadiums, banks, shopping centers, airports, train stations, information centers.
