Brand: LED SPEKTAR
Model: P10 Outdoor
Type: Two-color LED Module
Description:
1) High brightness, adjustable
2) High refresh rate
3) long life
4) Two years warranty
Technical Specification:
Pixel Pitch: 10 mm
Configuration of LEDs: 1R1G
Color configuration of the module: Red + Green
Native resolution (points / m2): 10000
Brightness (CD / m2): ≥7000
Grey Level: 14bit
Frame rates: ≥60HZ / S
Color issue: ≥687C
Refresh rate: ≥1000HZ / S
Best viewing distance: ≥12m
Viewing angle (left and right / up and down): 160 ° / 50 °
IP protection: IP65 / IP54
Life Expectancy:> 100,000 hours
Display Resolution (points): 32 × 16
Software: LED studio
Resolution ratio (W / H) (point): 96 × 96
Operating temperature: -10 ° C ~ 40 ° C
Operating voltage: 220 / 110VAC, 50 / 60Hz
Maximum power (W / m2): ≤850
Video: S-VHS, DVD, TV, Satellite, Color-camera, PC-VGA
Spare parts: LEDs, IC, cables, etc.
Dimensions (mm): 320 × 160
Size Box (W / H) (mm): 960 × 960
Net weight (kg): ≤47
Certificates: CE, ROHS, CCC
Application: For outdoor use
