Brand: LED SPEKTAR
Model: P2.5 SMD CHPSHWCFT
Type: Outdoor FullColour LED
Technical Parameters:
Module Specifications:
Pixel Pitch: 2.5mm
Lamp: SMD1921 NationStar
Pixel Configuration: 1R1G1B
Module Resolution: 128px * 64px
Module Pixels: 8000 pixels
Module Size: 320mm * 160mm
Module Weight: 1.5 kg
Cabinet Specifications:
Cabinet Size: 960*960*140
Cabinet Resolution: 384px*384px
Module Quantity in Cabinet: 18 pcs
Cabinet Pixels: 160 000 px
Average Power Consumption: 234W/m²
Max. Power Consumption: 781W/m²
Material: Aluminium
Cabinet weight: 28 kgs
Maintance: Rear Maintenance
Brightness: 3500cd/m²
Colour Temperature: 6000k ~ 8000k
Contrast: 4000:1
Driving Method: 1/13 scan
View Angle: H: 120° V: 120°
Optimal Viewing Distance: 5m-100m
Brightness Control: Red, Green and Blue 256 Grade Each
Refresh Frequenncy: 1920Hz
Frame Frequency: 50-60Hz
Input Voltage: AC220V/50Hz or AC110V/60Hz
Application: Malls, Cinemas, Advertisment, Show Programs
