Brand: OEM
Модел: P1.8
Type: LED Module
Functions:
Reliable, stable and guaranteed with a golden thread (Golden WIre).
Using PMW driver chip, 4k refresh rate.
PMW-SS dual power-saving driver IC, supports 4V low voltage start, double power saving and more energy saving.
With Mago box, free DIY, self-installation, comprehensive upfront support.
Standard universal size 320 * 160 mm.
Viewing angle ≥ 140° Multi-directional viewing is always the same.
High-end manufacturing products.
Technical Parameters:
Scanning method: 1/43
Pixel Pitch: 1.8
Module resolution: 172*86
Module size (mm): 320*160mm
Pixel density: 289,906 pixels/²
Brightness(cd/m²):≥600
Module weight: 0.47kg
Maximum voltage: ≤5.5A
Energy consumption: ≤580W/m²
Optimal viewing distance: ≥1.8m
LED Encapsulation: SMD1010/SMD1212
Driving IC:PWM-SS Driving IC
Refresh rate: ≥6000Hz
Brightness decay (3 years of operation): ≤ 15%
MTBF: ≥ 10,000 Hours
Percentage Defects: 0.03% <0.0003
Viewing angle: H160º / V160º
Grayscale: 14-15bits
Application: commonly used in video conference centers, information centers, demonstration centers and studios, indoor halls, television halls, exhibition halls, theater, government departments, conference rooms, entertainment venues, schools, hospitals, performing arts centers.
