Brand: KAIMANN
Model: KAIFLEX DUCT ALU 10мм
Type: thermal and sound insulation of ducts
Description: Kaiflex Duct is a flexible elastomeric insulating material with a closed cell structure. Thanks to its width of 1m it is easy to apply for duct insulation. Closed cell structure reliably prevents steam penetration and thus provides excellent insulation properties throughout the life of the system. Kaiflex Duct is made of self-extinguishing material, does not burn and does not drip during fire. This is a material with a lot of (up to 40 dB at a thickness of 15 mm in the frequency range 100-1200 Hz) Thanks to its soundproofing properties, dust-free structure and antimicrobial properties, Kaiflex Duct is suitable for use in public, commercial and industrial applications. radiators for heat and sound insulation of ducts in ventilation and air conditioning systems. For easier installation, Kaiflex Duct rolls can be produced with a self-adhesive layer reinforced with a fastening system.
Product benefits
Ventilation systems have many different components that work together to ensure a good supply of fresh air. To work effectively, the channels must be insulated. This is especially true for outdoor air ducts, where insulation is used outside or inside the condensation protection duct. With Kaiflex Duct, Kaimann offers a solution with an optimal insulation layer thickness for rectangular ventilation ducts and shafts, which insulates efficiently and economically.
Long-lasting productivity
Kaiflex Duct provides reliable long-term insulation. Closed cell foam withstands significant temperature differences between the surface of the duct and the surrounding air along with humidity, avoids corrosion and prevents energy loss - for the entire life of the system. Kaiflex Duct also effectively reduces the transmission of unwanted noise through ventilation equipment.
Economic isolation
Kaiflex is the cost-effective insulation solution for builders and construction operators with energy efficiency and quality requirements.
Reliable condensation prevention
Dew formation can damage the insulation as well as technical equipment. Thanks to its closed cell properties, Kaiflex keeps pipes and ducts dry and prevents corrosion under the insulation (CUI).
Meets high hygiene requirements
Kaiflex insulation materials do not contain dust and fibers for high hygiene requirements during installation and operation of the system.
Antimicrobial coating
Mold growth can affect indoor air quality. Kaiflex provides effective protection against moisture penetration and is a natural antimicrobial and resistant to mold growth, leaving bacteria without a chance.
Technical Characteristics:
Type of material: Highly flexible foam based on synthetic rubber, FEF (flexible elastomeric foam)
Structure: closed cell structure
color: silver
Sound insulation coefficient: 27 dB
Upper temperature limit: 70 ° C
Lower temperature limit: -40 ° C
Thermal conductivity: λ θ = 0.036 W / (mK)
Water permeability: μ> 7000
Fire Resistance: E
Corrosion resistance: meets the requirements - According to DIN 1988
Health aspects: No dust and fibers, No heavy metals (eg cadmium, lead) and formaldehyde
External use: Not intended
Roll size: 10x1m
Thickness: 20mm
Quantity in one roll: 6m²
Quantity in one pallet: 14 rolls / 84m²
Weight of the roll: 5.10 kg
Weight per m: 0.51 kg
Storage of the product: Store in dry and clean rooms at normal humidity (50-70%) and temperature (0 ° C to +35 ° C)!
External use: Not intended
Application: ventilation, air conditioning and refrigeration systems, car sound insulation, rectangular ventilation ducts and shafts.
