Brand: KV2 Audio
Model: ES1.0
Type: 3-way high output speaker
Description:
The ES1.0 is a 3-way, very high output, active-driven, mid-high / mid-bass module designed as part of a complete ES system, driven by the EPAK2500/R control and amplification unit. The ES1.0 is compact, lightweight and can be combined with a variety of ES series subwoofers. As a single system it offers one of the highest quality portable sound reinforcement solutions on the market today. When coupled with another ES1.0 (running two horizontally per side) it becomes an even more powerful tool, providing peak SPL of 139dB and a throw of up to 40 metres for applications of up to 3000 people.
Technical characteristics:
Features:
- Professional Baltic birch construction with wear resistant polymer coating
- 131dB sustained output, 134dB peak
- Controlled wide dispersion 90° x 40°, rotatable mid-high horn for mounting in vertical or horizontal orientation
- 1.75" (44 mm) Titanium diaphragm compression driver with complex geometry phase plug and neodymium magnetic structure for higher output, incredibly low distortion and extended frequency response
- 6" mid-range driver with a 1.75" (44 mm) voice coil and neodymium magnet for increased control and output with reduced distortion and weight
- Horn loaded, 12" mid-bass driver with a 3" (76 mm) inside/outside, epoxy baked, high temperature voice coil assembly and neodymium magnetic structure
- Three way active requirement – 900W from the EPAK2500/R providing 600W for the 12" low mid, 200W for the 6" midrange and 100W for the high frequency driver
- Proprietary side handle design for simlified handling and carrying
- High impact low friction feet, asymmetrically located on three sides allowing vertical or horizontal system set up, lock-in and easy cabinet movement
- Four internal corner braces tied to eight M10 suspension points. A total of 24 suspension points are available for custom installation applications
- Top hat for pole mounting applications
- Weather proofing option and special paint finishes available on request
System Acoustic Performance:
Max SPL Long-term: 131dB
Max SPL Peak: 137dB
-3dB Response: 130Hz to 20kHz
-10dB Response: 85Hz to 28kHz
Impedance Low: 16Ω Mid 8Ω High 8Ω
Crossover Point: 130Hz, 500Hz, 2.5kHz
High Frequency Section:
High Horn Coverage Horizontal / Vertical: 90° x 40° rotatable
High Frequency Amplifier Requirement: 100W from EPAK 2500/R
Throat Exit Diameter / Diaphragm Size: 1" / 1.75"
Diaphragm Material: Titanium
Magnet Type: Neodymium
Mid Range Section:
Acoustic Design: Horn Loaded
Mid Horn Coverage Horizontal / Vertical: 90° x 40° rotatable
Midrange Amplifier Requirement: 200W from EPAK 2500/R
Woofer Size / Voice Coil Diameter / Design: 6" / 1.75"
Diaphragm Material: Epoxy Reinforced Cellulose
Magnet Type: Neodymium
Mid Bass Section:
Acoustic Design: Horn Loaded
Mid-bass Amplifier Requirement: 600W from EPAK 2500/R
Woofer Size / Voice Coil Diameter / Design: 12" / 3" / Inside Outside
Diaphragm Material: Epoxy Reinforced Cellulose
Magnet Type: Neodymium
Speaker Input:
Speaker Input: AP6
Cabinet:
Cabinet Material: Baltic birch
Handles: 2
Pole Mount: 35 mm
Color: "Orange peeled" Matt Black or any RAL
Physical Dimensions:
Height: 700 mm (27.55")
Width: 450 mm (17.71")
Depth: 450 mm (17.71")
Weight: 34 kg (74.8lbs)
Product code:
KVV 987 002 - ES1.0
Technical Data Sheet can be viewed here
Official Product page can be viewed here
Application: Specifically designed as an extreme high output, compact mid-high enclosure as part of ES systems
● For live performance and music playback ● Small to large live concerts ● Small to medium nightclubs ● Houses of worship ● Portable PA ● Scalable into larger multi-tasking projects and systems
