Brand: TECHNOELASTICA
Model: TU-85
Type: sound insulation pad under
Note: Prices are per square meter!
Description: Insulation against vibration and airborne noise is made of light polyester wool, which contains separate elastomeric cushions and aims to optimize the impact sound insulation and the insulation of floor structures. The pad can be used in dry and wet floating floor structures, optimize and achieve a (very) low resonant frequencies. The substrate can easily be cut and processed.
Characteristics:
Elastic absorbent mat comes in rolls of 1.2 m width and 7.2 m in length, with a standard thickness of 50 mm. Pads are always cubic (50 mm) and are included in the wave distances of 0.4 m in both directions (Plan "A") or 0.6 m in both directions (plan "B"), depending on the load, which is intended be placed on the floor. Purpose - load on the concrete slab of 416 to 693 kg / m². The price per square meter!
The choice of the type of substrate depend on the following:
- The load, which is intended to be placed on the floor.
- The level of insulation required
- The type of flying, concrete or wood
- Contact surface (type and size)
