Brand: Sunricher
Model: SRP 75W
Type:
Description:
SRP 2309-75W is DALI-2 certified 75 W LED Driver with 4 parallel connected channels and 24VDC constant voltage output. It is designed with 100~277VAC universal Input. Power factor of the driver can be over 0.9 and efficiency is higher than 90%. It enables smooth and deep diming to 0.1% without flickering and buzzing noise. 1 DALI adress can be manually assigned via buttons and showed on digital display or automatically assigned by DALI Masters. Complying with IEC62386-101:2014, 102:2014, 207 ed.2, this DALI driver is compatible with DALI-2 certified application controllers and control devices. UL and ENEC certification ensures high safety and reliability performance of the driver to be used worldwide.
Key Features:
DALI-2 Certified 75W LED Driver
UL and ENEC certification
100~277VAC universal Input
Mains-powered control gear
DALI bus current consumption < 2mA
4 channels parallel connected channels output, 24VDC constant voltage
Class II power supply, full isolated plastic case.
Rubycon capacitors
Built-in active PFC function
High power factor and efficiency, PF > 0.9, Efficiency > 90%
Complying with IEC62386-101:2014, 102:2014, 207 ed.2 scallable system.
Support DALI-2 input devices: Occupancy, light sensor and push buttons.
Enables to control single color LED Lighting.
Fade time, system failure level, power on level configurable.
1 DALI adress can be manually assigned via buttons and showed on digital display or automatically assigned by DALI Masters.
Smooth and deep diming to 0.1% without flickering and buzzing noise.
Error report function.
IP20 rating, suitable for indoor LED lighting applications.
Technical Parameters:
Input voltage: 100 ~ 277VAC
Rated Power: 75W
Power Factor: >0.95
Total Harmonic Distortion: THD ≤ 15% (full load/ 230VAC)
Efficiency Current (Typ.): 86% @ 230VAC full load
AC Current (Typ.): 0.9A@ 100VAC , 0.39A @ 230VAC
Inrush Current (Typ.): COLD START Max. 2A at 230VAC
Leakage Current: Standby Power Consumption: <1W
Dimming Interface: DALI DT8 (DALI Consumption <2mA)/Push
Dimming Range: 0.1%~100%
Dimming Method: Pulse Width Modulation
Output voltage: 24VDC
Maximum output power: 75W
Output current: 3.12 A max
Dimensions: 64 * 244 * 32mm
Over Current: Yes, recovers automaticaly after fault condition is removed.
Over Temperature: Yes recovers automaticaly after fault condition is removed.
Working Temp.: -20°C~ +45°C
Max. Case Temp.: 85°C
Working Humidity: 10%~95% RH non-condensing
Storage Temp. & Humidity: -40°C ~ +80°C, 10% ~ 95% RH
Safety Standarts: EN61347-1, EN61347-2-13
Withstand Voltage: I/P-O/P: 3.75K VAC
Isolation Resistance: I/P-O/P: 100M Ohms / 500VDC / 25°C / 70% RH
Dimensions: 244*64*32mm (L*W*H)
Application: DMX Configurations
