Brand: SuperSound
Model: PT-24
Type: Non-waterproof
Technical Parameters:
Connecting mode: 1/4 mount connector
Protection level: IP44
Wire gauge: 14 ~ 12AWG
Current rating: 20A
Contact diameter/Number contacts: Φ2.0x3
Operating voltage:(AC.V.rms.): 500V
Withstand voltage(AC.V)1min: 2500V
Contact resistance: <3mΩ
Insulation resistance: >500MΩ
Durability: 500 mating/unmating cycle
Temperature rating: -40° ~ 80°
Connecting mode: Flat colder and screw
prohibited to charged inserted.
Materials:
1. Shells & Insulated parts:
- High performance engineer plastic
- Hardware metal: Zinc Alloy (Pearl hard chromium)
2. Contact: Copper alloy (Silver - plated)
