Brand: Audiophony
Model: MPX12
Type: Mixer
Description: Audio mixer with 12 channels, built-in processor, effects and integrated multimedia player.
Technical characteristics:
Mono channels
• Microphone inputs: Balanced
• Frequency response: 10Hz - 30KHz, +/-3dB
• THD (THD&N): 0.03% @ +4dBu, 22Hz-20KHz A weighted
• Compression: Gain: 0-9dB, Threshold: 20dB 5dB
• S/N ratio: 115 dB
• Line inputs: balanced
• Frequency response: 10Hz - 30KHz, +/-3dB
• THD (THD&N): 0.005% @ +4dBu, 22Hz-20KHz A weighted
• Maximum gain: 75 dBu 75 dBu Mic input Main output
Stereo channels
• Line inputs: balanced/unbalanced
• Frequency response: 10Hz - 55KHz, +/-3dB
• THD (THD&N): 0.005% @ +4dBu, 22Hz-20KHz A weighted
Impedances
• Microphone inputs: 1.4 K Ohms
• Line inputs: 10 K Ohms
• Other inputs: 10 K Ohms or better
• Recording input: 1 K Ohms
• Other outputs: 120 Ohms
Mono channel EQ
• High +/-15dB @ 12 KHz
• Average +/-15dB @ 2.5 KHz
• Low +/-15dB at 45 Hz
Stereo channels EQ
• High: +/-15dB @ 12 KHz
• Low: +/-15dB @ 60 KHz
• Multi-effect: 24-bit analog-to-digital converter, 16 programs
• Power supply: AC100~240V 50/60 Hz
• Size: (L x W x H): 330 x 392 x 92 mm
• Weight: 5.2 kg
