Brand: Master Audio
Model: SM-4000
Type: Power Amplifier
Description: Class H - 2 x 2000 W / 4 Ohms - 13 kg.
Current limiter to gradually gain limiter of the maximum power level without distortion.
Innovative design of cooling. Extensive protections: short circuit, overheating, DC offset, RF, OFF.
Technical specification:
Voltage Gain: 26 dB / 32 dB / 38 dB
Input Impedance: Balanced: 20KOm, unbalanced: 10KOm
Frequency response: 20Hz-20KHz
Input sensitivity 26 db / 32 db / 38 db
Slew Rate: +/- 20 V / us
Dumping factor:> 300
Signal / noise ratio> 108 db
Harmonic distortion THD: 1kHz, 1%
Crosstalk: 65 dB
Power 8 Om: 1200 W
Power 4 Om: 2000 W
Power 2 Om: 3000W
Power 8 Om Bridged: 4100W
Power 4 Om Bridged: 6200W
Power: ac voltage - AC 190-260V / 50-60Hz
Dimensions HWD (mm): 88 x 482 x 464 mm
Weight / gross (kg): 12 kg
Applicable Places: stadiums, concerts, DJ parties, discos, clubs, scenes
