Brand: Supersound
Model: HG800
Type: Amplifier
Audio Amplifier class H power:
8Ω stereo power: 2x800W
4Ω stereo power: 2x1200W
2Ω stereo Power: 1500W
8Ω bridge mode: 2350W
4Ω bridge mode: 3050W
Frequency Response: 20 Hz - 20 kHz
THD + N: <0.1%
Value signal / noise ratio:> 80 dB
Damping ratio> 200
Crosstalk:> 70 dB
Slew rate:> 20V / μs
Input Sensitivity: 26db / 32dB / 38db
Input impedance (bal / unbal): 10kΩ / 20kΩ
Gain voltage (8Ω): 38dB
Output circuit: 2-tier Class H
Cooling: Air flow from front to back
Protection: Soft start, DC, short circuit, overload, limiting, heat, progressive volume, VHF.
Connector: Input - XLR-F, XLR-M; Exit - Binding posts & NL4 SPEAKON
Indicator on the front panel: STY, Power, Signal VU, Clip, Protection, Parallel, Bridge
Front panel: Switch the power button for volume control
Rear panel: Stereo / parallel / bridge switch, switch inputs, soft clipping switch, grounding switch.
Dimensions (W x D x H) (mm): 483 x450x89 (mm)
Weight: 9.7 kg
Power supply: AC220V / 50Hz. ± 10%
Application: discos, clubs, karaoke bars.
