LED outdoor DISPLAY SMD 3in1 P10

Brand: LED SPEKTAR

Model: LED SMD 3in1 external display PH 10

Type: LED outdoor display RENTAL

Description: The outdoors LED displays offered by LED SPEKTAR have high brightness and frequency, which ensures crystal clear picture of the picture. The use of first-class LED chips from SILAN brand and ensures long life of LED display and clarity even in direct sunlight. The return on investment is fast due to their widespread use.

Technical characteristics: PH 10 5050 SMD 3 in 1

Pixel Pitch: 10 mm

Pixel density: 10000pix / m2

Type of LED: SMD5050 3 in 1

Wavelength of the LEDs: R: 622-627 / G: 522-525 / B: 463-465

Luminous intensity of the LEDs: R: 650-740 / G: 1560-1820 / B: 290-366

Viewing Angle: H 120 °, V120 °

Brightness: ≥5500cd / m2

Control method: 1/2 scan

Management IC: MBI5024

Colour Depth: 4096

Refresh rate (Hz): ≥900

Frame Rate (Hz): ≥60

Adjusting the brightness manually, automatically, SPC

Module Size (mm): 160x160x25

Module Resolution (pixel): 16x16

Size of cabinet (mm): 640x640x100

Display Resolution of the Cabinet (pixel): 64x64

Most good viewing distance: 10- 40 meters (depending on the screen size)

Material of cabinet: cast aluminum

Cabinet Weight (kg): 18 kg.

Power: 5V, 40A

Voltage (V): AC 86 - 264V

Max. Power consumption: 900W / m2

Medium (normal) Power consumption: 530W / m2

IP degree: front IP65, rear IP54

Temperature / humidity operation: -20º ~ 50º, 10 ~ 90% RH

Storage temperature / humidity: -40º ~ 60º, 10 ~ 90% RH

Life (Normal Temp):50000h

Control: Linsn/Novastar

Connecting cables: 120 m (CAT5E); 500m- 10km (optichnen cable)

Supported devices: DVI, DVD, HDVD, video camera

Compatible standards: CCC, CE

Applicable places: Annuity events, mobile media, outdoor advertising, stadiums, banks, shopping centers, airports, train stations, information centers.
