LCD Panel 46 "video wall

Brand: LED SPEKTAR

Model: LCD panel 46 "

Type: LCD Video Wall

Description: LLCD-46 is specifically designed for tile applications of video walls in small and medium-sized control rooms and premises. The depth of the module is less than 9 cm (including mounting hardware). This allows the video wall systems to be installed in limited spaces. The high resolution of the tiled LLCD-46 video wall allows operators to monitor very closely and observe quality video information. In combination with the controller can be observed video content from multiple sources (from the personal computer or streaming video). They can be presented and positioned anywhere across the LCD video system. This unique hyper-thin product can be calibrated and is able alone to regulate brightness in daylight. LLCD-46 video wall system includes an ultra quiet cooling system, designed to move hot air from the screen so that the heat may not be able to collect behind the screens.

Specifications:

Panel:

LLCD-46 (450mcd)

Size: 46 "
Width of board: 7.3 mm
Resolution: 1366 * 768
Pixel Pitch (mm): 0.7455 (H) * 0.7455 (V)
Dimensions of the module / active area of ​​the LCD panel (mm): 1018.353 (H) x 572,544 (V)

Contrast: 4500: 1
Brightness (typ.): 450 CD / ㎡
Colors: 8 bits - 16.7M
Viewing Angle (H / V): 178/178

Response Time (G to G): 8 ms

Colour: 8 bit - 16.7M.
Permanent Color range: 72%

Display:
Dynamic contrast ratio: 10,000: 1
Horizontal scanning frequency: 30kHz ~ 81kHz
Vertical scanning frequency: 56Hz ~ 85Hz
Pixel frequency (max.): 148.5MHz

Electronic features:

Type: internal synchronization
Electronic Source: AC 100-240 V ~ (+ / - 10%), 50/60 Hz
Open Position power: 205W (max.) / 185W (typical)
Hidden Power: Power Off State:

Connection:

RGB input: D-SUB, DVI-D
Video input: CVBS, HDMI1, HDMI2
Audio Input: RCA (L / R), stereophonic sound port
Output RGB: DVI-D (loop exit)
Video Output: N / A

Audio output: stereophonic sound port
Power Output: 5V (SBB)
External control: RS232C (Input / Output), RJ-45

Mechanical Features:
Dimensions (mm) Net size: 1025.7 * 579.8 130.0 *
Dimensions (mm) Packing size: 1148.0 * 705.0 330.0 *
Weight (kg) Net weight: 19.3
Weight (kg) Gross weight: 24.6
VESA port: 600 * 400MM
Screen protection: N / A
Stand: Stand feet (Optical)
Type: N / A
Operating temperature: 0 ℃ ~ 40 ℃
Operating Humidity: 10 ~ 80%

Certificates:

CE, EN55022, EN55024

Environment: ENERGY STAR 5.0 (USA)

Application: Small and medium-sized control rooms.
